Removes damaged glow plugs, even when compartment is not easily accessible
Easy removal in narrow engine bays and engines with glow plugs on the firewall side
Enables removal of broken glow plugs from the top of the cylinder head without damage to other components
Includes (1) electrode puller, (1) electrode reinforced drill with (2) guides, (2) specially centered mills with one mill support preventing damage to the head, (1) tap and (1) slide hammer extractor to pull out broken glow plugs, (3) refreshing taps sizes: M8, M10x100 & M10x125 with hex drive
Applications include, but not limited to: Chevrolet Silverado HD, Kodiak, GMC Sierra HD, TopKick, Savana, Ford E-Series, F-Series, Excursion, Transit, Dodge RAM 2500+, Nissan Titan XD & MORE!

Video

Components

Key	CTA #	Description
1	7804X1A	Slide Hammer Counter Weight
2	7804X1B	Slide Hammer Bar
3*	7804X1C	Tap M6 x 100
4*	7804X1D	Thread Repair Tap M8 x 100
5*	7804X1E	Thread Repair Tap M10 x 100
6*	7804X1F	Thread Repair Tap M10 x 125
7*	7804X1G	Milling Drill M8
8*	7804X1H	Milling Drill M10
9	7804X1I	Drill Holder
10	7804X1J	M6 x 100 Puller
11	7804X1K	Set of 2 Guides
12*	7804X1L	Drill 2.5mm
13	7804X02	Plug Puller Adapter
14	7804X03	Extractor Screws (2)
15	7804X04	Hex Nut
16	7804X05	Electrode Puller Screw

Warnings

WARNING: DOES NOT WORK ON 2006-2016 (6.6L DURAMAX) CHEVROLET SILVERADO, EXPRESS & GMC SIERRA, SAVANNA WITH GLOW PLUGS THAT HAVE THREADS NEAR THE MIDDLE OF BODY. PART #12639701 9G

WARNING: DOES NOT WORK ON CERAMIC GLOW PLUS.

WARNING: 300 RPM MAX SPEED FOR MILLING DRILL BITS.

Application Guide

Vehicle Make	Models	Years	Thread Size	Notes
Chevrolet	Silverado HD, Kodiak, Express	Various	M8, M10x1.00, M10x1.25	Compatible with models where glow plugs have standard thread sizes. Not compatible with models using glow plugs with middle-body threads.
GMC	Sierra HD, TopKick, Savana	Various	M8, M10x1.00, M10x1.25	Same as Chevrolet compatibility.
Ford	E-Series, F-Series (Super Duty), Excursion, Transit	Various	M8, M10x1.00, M10x1.25	Ideal for models with glow plugs located on the firewall side or in narrow engine bays.
Dodge	RAM 2500, RAM 3500, RAM 4500, RAM 5500	Various	M8, M10x1.00, M10x1.25	Designed for tight engine compartments in heavy-duty diesel trucks.
Nissan	Titan XD	Various	M8, M10x1.00	Provides easy access to glow plugs in restricted engine spaces.
Volkswagen	Golf, Jetta, Passat, Touareg (Diesel variants)	Various (TDI engines)	M8, M10x1.00, M10x1.25	Compatible with Volkswagen diesel engines, including TDI models with standard thread glow plugs.
BMW	X5, 3 Series (Diesel variants)	Various	M8, M10x1.00	Works on BMW diesel models with standard thread glow plugs.
Mercedes-Benz	Sprinter, G-Class (Diesel variants), E-Class (Diesel)	Various	M8, M10x1.00	Compatible with Mercedes diesel engines using standard M8 and M10x1.00 thread glow plugs.
Jeep	Grand Cherokee (Diesel variants), Wrangler (Diesel)	Various	M8, M10x1.00	Suitable for Jeep diesel engines with narrow access areas.
Audi	A3, A4, Q7 (Diesel variants)	Various	M8, M10x1.00	Designed to handle Audi diesel engines with M8 and M10 thread glow plugs.
Fiat	Ducato (Diesel variants)	Various	M8, M10x1.00	Compatible with Fiat diesel models using standard glow plug threads.
Renault	Master, Trafic (Diesel variants)	Various	M8, M10x1.00	Works on Renault diesel models with compatible thread sizes.
Isuzu	NPR (Diesel models)	Various	M8, M10x1.00, M10x1.25	Suitable for Isuzu diesel engines, commonly used in commercial vehicles.
Toyota	Hilux (Diesel models), Land Cruiser (Diesel models)	Various	M8, M10x1.00	Ideal for Toyota diesel trucks and SUVs with limited engine bay access.
Citroën	Berlingo, Jumper (Diesel models)	Various	M8, M10x1.00	Compatible with Citroën diesel vehicles.
Peugeot	Boxer, Expert (Diesel models)	Various	M8, M10x1.00	Suitable for Peugeot diesel engines using standard thread glow plugs.
